Motors(PMSM) 13 Series
Motors(PMSM) 13 Series
Model | 1303 | 1306 | 1309 |
Operating Voltage(V) | 72-96 | 72-96 | 72-96 |
Rated Power(Kw) | 5 | 10 | 15 |
Peak Power(Kw) | 10 | 20 | 30 |
Rated Speed(rpm) | 5730 | 5730 | 5730 |
Peak Speed(rpm) | 12000 | 12000 | 12000 |
Rated Torque(N.m) | 8 | 16.7 | 25 |
Peak Torque(N.m) | 25 | 53 | 76 |
Weight(kgs) | 7 | 9.7 | 12 |
